The S5000 is a medium-sized control surface for the dLive MixRack, with the addition of built-in audio I/O and audio networking ports. It features 28 faders over 6 layers, dual 12″ capacitive touchscreens and the innovative Harmony UI for the fastest workflow in the industry.

• 28 faders

• Fully assignable layout - 168 fader strips

• Harmony UI integrates screen and wrap-around controls

• Dual 12" capacitive touchscreen

• Gesture control - pinch, swipe, drag 'n drop

• Dedicated multi-mode EQ view

• Configurable widget areas for Scenes, meters, FX and more

• 3 pages of 6 assignable rotaries per screen

• 26 assignable SoftKeys

• Engineer's Wedge and IEM fader strips

• Comprehensive multipoint metering

• Daylight visibility

• USB stereo recording and playback

• 8 XLR mic/line in, 8 XLR line out

• 2 digital i.e. AES3 in, 3 digital i.e. AES3 out

• Connection hub

• Dual redundant GigaACE gigabit link to MixRack

• 1x redundant DX link for I/O expansion

• 2x I/O Ports - 128 ch 96 kHz each

• 2x Network ports

• Wordclock BNC I/O

• Video output

• Dual redundant, hot swappable power supply
