  • LIGHT SKY - MINI LUNAR BEAM

    Kodas: LIGHT SKY - MINI LUNAR BEAM

    Mini Lunar moving head lights can create various color effects to meet the needs of different scenes. The light sky is committed to providing all customers with high-quality mini-beam lights; if you are interested in mini stage lights, please get in touch with us, and our expert team will get back to you as soon as possible.

  • Light Source / Power System

    Voltage : AC100-240V 50/60Hz;
    Power :400W PF : 0.987;
    DMX and RDM connectors : Locking 3 pin or 5 pin XLR IN/OUT
    Power connector : Seetronic one in one out
    Light source : USHIO NSL 301
    Light source power : 300W
    Light source average life span : 2000h
    Total lumen output : 19000 lm
    Output color temperature : 7300 K
    CRI : 80
    Ballast : Electronic
    Front lens diameter : φ150 mm
    Luminance : 375000 lux @10m



    Color / GOBO / Effects

    Beam range : 1.8° beam angle (0.6° / 1.2° beam angle selection)
    Colour Wheel : Color wheel : 12 color + 2 CTO + 1 blank
    Static gobo wheel : 11 Gobos + open + 3 animations range ,Bi-direction flow water
    Prism : With 8 facet prism+24 face prism+prism combination
    Frost : adjustable wash effect angle
    Focus : Motorized focus
    Strobe : Electronic pulse strobe and random strobe
    Dimmer : 0 to 100% linear dimmer



    Control System

    Pan/Tilt : 540°/270°
    Pan / Tilt Resolution : 2.11°/1.05°
    Pan / Tilt Speed : 2.7S/1.6S
    IP Set : RDM two-way data transmission,Remote reset DMX address.
    Display : The display panel adopts a 1.77-inch TFT screen
    Noise level control : High brightness mode; Standard mode;Silent mode
    Intelligent control : Display board can record device’s using time , show device’s temperature, channel data and software version .
    Software upgrade : Upgrade with DMX
    Control protocol : DMX512, RDM
    Channel mode : 14CH、16CH 、16 PLUS



    Appearance Parameters

    Housing : Engineering plastic PA66
    Hanging system : foldable light hook
    IP rate : IP20
    Light dimension : 335x210x477mm
    N.W : 15.4Kg/pcs
    Carton dimension : 410x290x575mm
    G.W with carton : 18.5Kg
    Flycase dimension : 660x500x720(mm)
    G.W with fly case : 62.8Kg(2 in 1)
    Flycase dimension : 820x685x720mm
    G.W with fly case : 106.6Kg(4 in 1)
