Light Source / Power System

Voltage : AC100V-240V / 50-60Hz
Power : 800W，PF0.985
Luminous flux : 12205 Lm
LED chip : 19pcs×40W RGBW 4 in 1 LED
Average life : 30000h
optical system : High precision combination structure, high permeable glass light rod +PMMA lens

Color / GOBO / Effects

Zoom angle : 4.5°～60°. Linear electric zoom
Beam : small degrees beam effect
Wash : middle and big degree wash
FX mode : kaleidoscope effects
Color : RGBW macro color system.
Color temperature adjustable range : 2500～10000K
CRI : Ra≥75
Effect macro : Static effect macro functions and Dynamic effects macro function
Strobe : 1-30Hz electronic strobe and random strobe.
Dimmer : 16Bit, 0 to 100% Linear electronic dimmer，provides four dimming options

Control System

Lens rotation : Front lens rotation: 360 degree, infinite rotation
Front ring AURA : The front ring AURA ’s LED chip can be controlled individual.
Individual LED control : Independent Individual LED control
Pan/Tilt : Pan/Tilt Travel : 540°/218°; Pan/Tilt Fine : 2.11°/0.85°; Pan/Tilt Speed : 2.5S/1.2S
Control Mode : DMX512、RDM、ArtNet、 wireless DMX512 (option)。
Channel : Standard1(26CH)、Mode2(45CH)、Mode3(98CH)、Mode4(79CH)、 Mode5(22CH)、 Mode6(16CH)、Mode7(39CH)、Mode8(35CH)
Display : 1.91 inches OLED display screen. With Chinese and English two version language.
Working mode : Auto mode、Stage mode、Studio mode
Intelligent control : Display board can record device’s using time , show device’s temperature, channel data and software version .

Other functions

Error alarm : Automatic alarming for fixture error
IP set : built-in long-life battery, can set address without power connection
Software upgrade : Upgrade via DMX connector
Magnetic encoder : non-touch magnetic rotation encoder ,100% correct position memory
RDM : RDM signal two-way transmission
Safety Devices : Overcurrent and overheating protection.

Appearance Parameters

Outlooking : Metal base and anti-fire plastic.
IP rate : IP66
Light size : 470×333×563mm
Box Size : 530×395×635mm
N.W : 29.0kg G.W : 32.8kg
Flight case Size(2pcs in 1) : 925×580×785mm
N.W : 58.0kg G.W : 101.8kg
