FEATURES

• Onboard DMX

• Internal remote control storage

• Timer and output level remote control

• Linkable - up to 4 units can be operated at the same time with one remote. DMX - unlimited channels are available

• Optional flying kit

• Continuous output

• 580 m³/min fog output

• 1150 W (240V) / 1000 W (110V) heat exchanger

• 9 min heat-up time

• 3.8 liter fluid capacity

• Different fluid options for different applications

SPECIFICATIONS

PHYSICAL
          Length: 500 mm (19.7 in.)
          Width: 232 mm (9.2 in.)
          Height: 266 mm (10.5 in.)
          Dry weight: 15.0 kg (33.1 lbs.)
PERFORMANCE
          Max. fog output (approx.): 580 m3 per minute
          Max. operating time at full output (approx.): 90 minutes
          Operating time: Continuous, automatic level adjustment
          Warm-up time (approx.): 9 minutes
CONTROL AND PROGRAMMING
          Control options: Remote control (supplied), DMX
          Remote control features: Instant or timer-controlled variable output
CONSTRUCTION
          Housing: Steel & aluminum
          Heat exchanger: 1150 W (240V) / 1000 W (110V), direct thermal protection
FLUID SYSTEM
          Fluid pump: Oscillating piston, high pressure
          Onboard fluid capacity: 3.8 l
          Fluid consumption at peak output: 70 ml per minute
INSTALLATION
          Orientation: Floor or flown in optional hanging bracket
CONNECTIONS
          DMX: 3-pin locking XLR
          Remote control: RJ-45
          Power cable entry: 3-pin IEC
ELECTRICAL
          AC power (EU models): 220-240 V nominal, 50 Hz
          AC power (US models): 110-120 V nominal, 60 Hz
          Main fuse (220-240 V power): 6.3 AT (slow blow)
          Main fuse (110-120 V power): 10 AT (slow blow)
TYPICAL POWER AND CURRENT
US model:
          110 V, 60 Hz: 874 W, 7.95 A
          115 V, 60 Hz: 955 W, 8.3 A
          120 V, 60 Hz: 1040 W, 8.6 A
EU model:
          220 V, 50 Hz: 1089 W, 4.95 A
          230 V, 50 Hz: 1190 W, 5.2 A
          240 V, 50 Hz: 1296 W, 5.4 A
          Measurements made at nominal voltage. Allow for a deviation of +/- 10%.:
THERMAL
          Maximum ambient temperature (Ta max.): 40° C
          Exterior surface temperature, steady state: 50° C
          Max. nozzle temperature: 200° C
