Technical specifications

• FREQUENCY RESPONSE:  (-10 dB) 28 Hz – 160 Hz

• AVERAGE DISPERSION: Quasi-omnidirectional

• IMPEDANCE: 2 x 8 Ω (min 2 x 6.2 Ω)

• POWER – WAES: 2 x 1200 (2 x 4800 peak)

• MAX SHORT-TERM SPL @ 1 m*: 141 dB SPL (free-field) 147 dB SPL (half-space)

• LOUDSPEAKERS AND LOADING: 2 x 18″ hybrid band-pass loaded woofers

• WEIGHT – SINGLE UNIT: 93.5 kg (206.1 lb)

• DIMENSIONS: Height: 605 mm (23 26/32″) Width: 1124 mm (44 8/32″) Depth: 650 mm (25 19/32″)

* calculated using +10 dB crest-factor signal
